Double Glazed Unit (DGU)

Double Glazed Unit (outer: 6mm with coating Face 2 - 12mm Air Gap - inner 6mm Clear)

Glass Type: Architectural Glass
Glass Code: KT 464
Series: Nano
Colour: Green
Colour Shade: Citron Frost
Stock Sheet: 3660X2440, 3210X2250, 3210X4500, 3210X 4880, 3210 X 5100, 3210X6100 mm
Inside Glass Thickness: 6 mm
Air Gap: 12 mm
Outside glass Thickness: 6 mm
Coating: Single Silver Coating
TR: 47
ER: 11
IR: 10
SF: 0.33
SC: 0.37
UV: 1.9

Comprehensive services and tools to support your Double Glazed Unit (DGU) project needs

Model double glazing units with load sharing factors (LS1/LS2).

Calculate single glazing deflection and stress under wind load.

No documents available for this product

We follow 4-point checks at our factory for quality assurance of Double Glazed Unit (DGU)

Raw materials check
As soon as the raw materials come into production units, they undergo test at our labs to get their properties checked, passing which they go to the store.
Product Check
The product thus manufactured, undergoes the most stringent test according to global standards, passing which it qualifies for dispatch.
Check at the manufacturing stage
At different stages of manufacturing, tests are done to validate if the purpose of a particular stage has been served or not. For e.g at the pre-treatment stage it is checked whether degreasing or deoxidizing of the aluminium coil has properly taken place or not.
Post production check
Before being dispatched, thorough visual inspection is done to check product tolerances and any other kind of manufacturing defect.
