Giesse GS-HD Top-Hung Arm – Type M - Hinges

Product manufacturer

Product Category

Hinges

Giesse Hinges GS-HD Top-Hung Arm – Type M

GS-HD Type M top-hung arms are designed for small to medium windows with medium/low load capacity. Tested for durability and smooth performance, these arms are suitable for aluminium window systems with 18 mm groove and 13.5 ± 0.5 mm sash-frame distance. Provides wide opening angle up to 87° (70° for 8" size). Supplied in pairs.

Code: 08201, 08202, 08195, 08196, 08197, 08198
Bag Width: 18 mm
Sash Frame Distance: 13.5 ± 0.5 mm
Arm Length: 214, 270, 310, 358, 412, 459 mm

Loading specs...

Suppliers & Dealers

0 dealers found

Applicators & Contractors

0 installers found

More Products fromGiesse

GS-HD Side-hung Arm – Type A

Giesse

₹1,600

GS-HD Side-hung Arm – Type M

Giesse

₹1,350

GS-HD Side-hung Arm – Type C

Giesse

₹2,500

GS-HD Type C Plus Super – Self-Balancing Side-hung Arm

Giesse

₹3,100

GS-HD Type TS – Multi-Position Side & Top Hung Arm

Giesse

₹2,800

GS-HD Limitation Arm – Side Hung (Friz / With Lock)

Giesse

₹1,050

Services & Tools

Comprehensive services and tools to support your Hinges project needs

No active Tools & Services currently

Product Comparison

Complete Technical Specifications for Giesse GS-HD Top-Hung Arm – Type M

Property	Value	Unit
Code	08201, 08202, 08195, 08196, 08197, 08198	—
Bag Width	18	mm
Sash Frame Distance	13.5 ± 0.5	mm
Arm Length	214, 270, 310, 358, 412, 459	mm
Maximum Sash Opening angle	70, 87	°
Max Height	350, 400, 550, 650, 750, 850	mm
Max Width	1200	mm
Max Weight	12, 16, 20, 22, 24, 26	Kg
Application	Top-hung windows (small to medium size)	—
Type of One-Way Stroke	—	mm
Rod Length	—	mm
